2.5L 4D56 Turbo Diesel Maintenance Routine
Timing Belt, Seals and SHine up
Every van that goes through our hands gets “The Nomadic Maintenance Routine”. An integral part of this routine is replacing all of the belts and seals. If that means we have to pull the engine to replace the rear main seal (the seal sandwiched between the transmission and the engine) we absolutely will. During this process we meticulously clean the engine. While the aesthetic payoff is great; this process allows us to see any leaks once the engine is back together.
4D56 Turbo Diesel Engine Specifications:
Manufacturer: Kyoto Engine Plant, Hyundai Ulsan Plant
Production years: 1986-2016
Displacement: 2477cc
Fuel system: Common Rail
Power output: 84/4200 hp
Torque output: 201/2000 Nm
Cylinder block: Cast Iron R4
Block head: Aluminum 8v / 16v
Cylinder bore: 91.1mm
Piston stroke: 95mm
Compression ratio: 21.0
Hydraulic lifters: No
Timing drive: Belt
Turbocharging: Yes
Recommended engine oil: 15W-40
Engine oil capacity: 6.5 Liters
Fuel Type: Diesel
Engine Lifespan: ~400,000km
Weight: 193kg
A full mechanical inspection is completed by a Delica technician. Process is as follows but not limited to:
Nomadic refurbished water pump
Nomadic refurbished alternator
New valve cover gasket
Valve clearance adjusted
Camshaft inspected for wear
Glow plugs replaced when necessary
Manual glow plug switch installed
Manifold gaskets inspected (Replaced if needed)
Injectors inspected (Replaced if leaking)
Turbo inspected
Engine Maintenance:
Engine oil & filter changed
Air filter replaced
Fuel filter replaced
Fuel lines inspected
Injection pump inspected for leaks
Serpentine belts replaced
Timing belts & tensioners replaced
5 Front end oil seals replaced:
Camshaft, injection pump,
crankshaft, balance shaft A & B
Water pump
All of our water pumps are refurbished and painted “Mitsubishi red”, and all gaskets are replaced in the process.
Alternator
Every van’s alternator is inspected, cleaned and tested for voltage output. The brushes, regulator and bearing are often replaced to ensure reliability.
Drivetrain, Brake, & Suspension Service
We want you to drive straight and stop quickly! This service includes but is not limited to:
- Replacement of front and rear shocks.
- Inspecting drivelines and U-joints; replacing/repairing when necessary.
- Inspecting front A-Arm bushings; replacing when necessary.
- Inspecting auto locking front hubs for proper functionality, bearings repacked during service.
- Inspecting and adjusting front torsion bars.
- Inspecting front brake rotors, calipers, and pads; replacing when necessary/brakes bled when necessary.
- Inspecting and repairing rear drum brakes.
- Inspecting, cleaning and greasing of all ball joints; replacing when necessary.
- Inspecting front and rear differentials & axles for leaks; replacing seals when necessary.
- Inspecting rear shackle bushings; replacing when necessary.
- Inspecting wheel bearings; replacing when necessary.
Cv axle boot
Over years of wear and tear the CV axle boots break down and rip apart. This allows dirt and grime into the articulating joint, which will destroy your CV axle. We make sure to check all CV axle boots, replacing when necessary, thus preventing CV axle demise:
Top End Adjustment
At Nomadic we want to ensure you are getting the peak performance out of your 4D56 Turbo-Diesel engine. The valve cover is removed and polished, while we adjust the valve clearance to back to .25mm. All of the valves, rocker arms and the camshaft are visually inspected for any signs or wear. If wear is present, parts are replaced.
At Nomadic we value transparency with our customers. Any questions about our process? Please shoot us a question on the Contact tab. More pictures of our maintenance routine are coming soon…
